Model	Xerox® Nuvera® 288 EA	Xerox® Nuvera® 314 EA	Xerox® Nuvera® 288 MX	Xerox® Nuvera® 314 MX
Rated speed	8.5″ x 11″ media: 288 duplexed images per minute 11″ x 17″ media: 144 duplexed images per minute	8.5″ x 11″ media: 314 duplexed images per minute 11″ x 17″ media: 157 duplexed images per minute	8.5″ x 11″ media: 288 duplexed images per minute 11″ x 17″ media: 144 duplexed images per minute	8.5″ x 11″ media: 314 duplexed images per minute 11″ x 17″ media: 157 duplexed images per minute
Resolution	Print: 4800 x 600 dpi RIP: 1200 x 1200 dpi	Print: 4800 x 600 dpi RIP: 1200 x 1200 dpi	Print: 4800 x 600 dpi RIP: 1200 x 1200 dpi	Print: 4800 x 600 dpi RIP: 1200 x 1200 dpi
Recommended average monthly volume	3,000,000 images per month	4,000,000 images per month	3,000,000 images per month	4,000,000 images per month
Duty cycle	up to 7,800,000 images per month	up to 8,500,000 images per month	up to 7,800,000 images per month	up to 8,500,000 images per month
MICR	No	No	Yes	Yes

Resolution	Print: 4800 x 600 dpi RIP: 1200 x 1200 dpi
Line Screens	85, 106, 125, 134, or 156 lpi

Standard Capabilities	Production printing and finishing
Printed Sides	Duplex

PDLs	TIFF, PCL6 (standard) Adobe® PostScript® Level 3, PDF, ASCII, VIPP®/PostScript, PPML, LCDS, IPDS, and IPV6 (optional)
Network Interfaces	Ethernet interface (10/100BaseT; 1 GB)
User Interface	19″ flat panel monitor, USB keyboard, USB mouse
CPU	3 GHz Dual Core Processor with 2 GB memory
Memory	4 GB
Hard Disk	160 GB SATA

Paper sources	up to 3 feed modules (4 paper trays per module), plus an optional post-print insertion module
Standard paper capacity	3,200 or 5,800 sheets per module Standard sheet feed module (4-tray): 5,800 sheets Oversized high capacity sheet feed module (2-tray): 3,200 sheets
Media Dimensions – Minimum	5.5 x 8 inches
Media Dimensions – Maximum	12.6 x 19.3 inches
Media Weight – Minimum	Coated: 90 gsm Uncoated: 44 gsm
Media Weight – Maximum	Coated: 300 gsm Uncoated: 300 gsm
Media Types	Coated: gloss, silk, matte Uncoated: book, text, bond, cover, Bristol, index, offset Specialty: carbonless, tabs, envelopes, never tear, preprinted offset forms

High Capacity Feeder	Standard Four-tray Sheet-feed Module: 5,800 sheets Oversized High-Capacity Sheet Feed Module: 3,200 sheets, up to 12.6″ x 19.3″ Roll Feed Solution: uses SheetFeeder NV in conjunction with standard four-tray sheet-feed module
Other Input Devices	Post-print Four-tray Paper Insertion Module: 5,800 sheets Post-print Oversized Two-tray Paper Insertion Module: 3,200 sheets

Top Tray	250 sheets
Stacker	Xerox DS-3500: 3,500 sheets, jam offset recovery/sheet-level recovery Xerox Production Stacker: 2,850 sheets, unload while run with single unit, waist height delivery, jam offset recovery/sheet-level recovery

Electrical Requirements	Dual 187-240 Vac, 50 amp, 50/60 Hz wall service
Dimensions	Print Engine: W: 88″; D: 29″; H: 61.6″ Sheet Feed & Insertion Module: W: 31.7″; D: 28″; H: 44.6″ Sheet Enhancement Module: W: 15″; D: 28″; H: 41.5″ Basic Finisher Module: W: 33″; D: 28″; H: 44.6″ Basic Finisher Module Plus: W: 49″; D: 28″; H: 44.6″ Finishing Transport Module: W: 35.6″; D: 28″; H: 46.3″
